Airtac SILF Front Locking Air Cylinder SILF63X600-S
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF63X600-S Front Lock Cylinder Specifications
- Model: SILF63X600-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63mm
- Stroke: 600mm
- Operating pressure: 0.1–1.0 MPa
- Lock holding force: 2,500N (max)
- Lock release pressure: ≥0.3 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/2
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + PU combination
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: 8.7kg (with lock mechanism)
- Dimensions: 1,130mm(L) × 95mm(W) × 95mm(H)
Heavy-duty lock cylinder featuring dual safety mechanisms: spring-assisted mechanical lock and pneumatic safety circuit. The hardened stainless steel lock pin engages during power loss or emergency stop, preventing unintended movement. Optimized for vertical installations with anti-vibration design in locking components.
- Automated welding positioners requiring position hold
- Elevator emergency braking systems
- Press machine tooling retention
- Overhead material handling systems
- Wind turbine blade adjustment mechanisms
Installation note:
Lock mechanism requires manual release during initial setup.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
Avoid side-load exceeding 10% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SILF63X600-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 600mm |
| Lock Position | Front Cover with Lock |
