This model is discontinued
AirTAC has phased out the SU series. You can still order this code here: we ship the direct replacement SAUJ100X100-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUJ Adjustable Cylinder SUJ100X100-10
The AirTAC Airtac SUJ Adjustable Cylinder SUJ100X100-10 is a double-acting profile-type standard cylinder with a Ø100mm bore and 100mm stroke, 1/2" air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAUJ100X100-10, which matches its bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke100 mm
- Port size1/2"
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAUJ100X100-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SUJ Adjustable Cylinder SUJ100X100-10
The AirTAC SUJ100X100-10 is a discontinued double-acting double-rod profile cylinder with an external stop screw that lets you trim the extend stroke by up to 10 mm on-site, yielding a usable 90-100 mm stroke. This compact extruded barrel is shorter than an ISO 15552 cylinder of the same bore.
This SKU is discontinued and the direct replacement is the SAUJ100X100-10, retaining the same bore, stroke, force, port, and FA/LB mounting. The SAUJ upgrade uses current CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B switches used here. As a non-magnet model, this cylinder cannot take a magnetic switch.
Airtac SUJ Adjustable Cylinder SUJ100X100-10 Technical Specifications
| Model | Airtac SUJ Adjustable Cylinder SUJ100X100-10 |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUJ100X100-10 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/2" |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUJ100X100-10 carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAUJ100X100-10 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUJ Adjustable Cylinder SUJ100X100-10
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUJ Adjustable Cylinder SUJ100X100-10 Is Used
Press Fit Tuning
Allows operators to dial in the final 10 mm of extend stroke on-site for pressing bearings without machining hard stops.
Transfer Diverter
Provides adjustable end-positioning for a diverter gate where product sizes vary and exact 90-100 mm extension is set during commissioning.
Pallet Stopper
Offers a field-tunable hard stop for pallets on a conveyor, letting maintenance shorten the extend stroke by up to 10 mm as wear occurs.
Replacing the Airtac SUJ Adjustable Cylinder SUJ100X100-10 with the SAUJ100X100-10
To replace the discontinued SUJ100X100-10, use the direct replacement SAUJ100X100-10, which matches the 100 mm bore, 100 mm stroke, 1/2" port, and FA/LB mounting. Choose the 10 mm adjust window when you need minor field stroke tuning between 90-100 mm. The stop screw sets the end position but is not a load lock; for load holding on air loss, specify an external rod lock or pilot-operated check valve. For stroke lengths of 300 mm or greater, verify the side-load bearing limits. Since this is a non-magnet SKU, you cannot mount sensors; the SAUJ replacement with the -S option supports CMSG/DMSG/EMSG sensors.
Replacement checklist
- ✓ Same bore / stroke → SAUJ100X100-10
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUJ Adjustable Cylinder SUJ100X100-10 FAQ
Yes, the SUJ100X100-10 is discontinued. The SAUJ also uses current CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B.
The external stop screw provides a 10 mm adjust window, meaning the usable extend stroke is 90-100 mm. The stop sets end position and is not a load lock.
