This model is discontinued
AirTAC has phased out the SU series. You can still order this code here: we ship the direct replacement SAUJ100X100-10S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUJ Adjustable Cylinder SUJ100X100-10S
The AirTAC Airtac SUJ Adjustable Cylinder SUJ100X100-10S is a double-acting profile-type standard cylinder with a Ø100mm bore and 100mm stroke, 1/2" air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAUJ100X100-10S, which matches its bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke100 mm
- Port size1/2"
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAUJ100X100-10S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SUJ Adjustable Cylinder SUJ100X100-10S
The AirTAC SUJ100X100-10S is a discontinued double-acting double-rod profile cylinder with an external stop screw that lets you trim the extend stroke by up to 10 mm on-site, giving a usable extend range of 90-100 mm. It features a 1/2" port, a 25 mm rod, M20x1.5 rod thread, and 29 mm adjustable cushions. This stop screw sets the end position; it is not a load lock, so use an external rod lock for held loads.
As a discontinued unit, the direct replacement is the SAUJ100X100-10S, matching the bore, stroke, force, port, and FA/LB mounting. The SAUJ upgrades to current CMSG/DMSG/EMSG sensors, whereas this SUJ used legacy CS1-B/DS1-B switches. The compact profile barrel is shorter than an ISO 15552 cylinder of the same bore.
Airtac SUJ Adjustable Cylinder SUJ100X100-10S Technical Specifications
| Model | Airtac SUJ Adjustable Cylinder SUJ100X100-10S |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUJ100X100-10S |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/2" |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUJ100X100-10S carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAUJ100X100-10S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUJ Adjustable Cylinder SUJ100X100-10S
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUJ Adjustable Cylinder SUJ100X100-10S Is Used
Press Fit Calibration
Trimming the extend stroke by up to 10 mm on-site allows precise bottoming force for pressing bearings without machining hard stops.
Transfer Diverter Positioning
Field-tuning the 100 mm extend endpoint ensures a diverter gate meets varying product profiles perfectly on the line.
Carton Sealing Stroke Trim
Adjusting the extend stop on-site accommodates different carton heights, ensuring precise flap folding without repositioning sensors.
Replacing the Airtac SUJ Adjustable Cylinder SUJ100X100-10S with the SAUJ100X100-10S
To replace the discontinued SUJ100X100-10S, order the direct replacement SAUJ100X100-10S, which preserves the 100 mm bore, 100 mm stroke, 10 mm adjust window, 1/2" port, and FA/LB mounting. The 10 mm adjust window is ideal for fine-tuning the extend position without shims. Because this unit has the -S magnet, you must upgrade from legacy CS1-B/DS1-B switches to current CMSG/DMSG/EMSG sensors on the SAUJ. For strokes of 300 mm or longer, verify side-load limits to prevent guide wear. Mounting compatibility is strictly with the AirTAC SC series.
Replacement checklist
- ✓ Same bore / stroke → SAUJ100X100-10S
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUJ Adjustable Cylinder SUJ100X100-10S FAQ
Yes, the SUJ100X100-10S is discontinued. The direct replacement is the SAUJ100X100-10S, which matches the 100 mm bore, 100 mm stroke, 10 mm adjust window, 1/2" port, and FA/LB mounting. The SAUJ uses current CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B switches.
The external stop screw window is 10 mm, allowing a usable extend stroke of 90-100 mm. The stop sets end position and is not a load lock.
