This model is discontinued
AirTAC has phased out the SU series. You can still order this code here: we ship the direct replacement SAUJ100X100-40S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUJ Adjustable Cylinder SUJ100X100-40S
The AirTAC Airtac SUJ Adjustable Cylinder SUJ100X100-40S is a double-acting profile-type standard cylinder with a Ø100mm bore and 100mm stroke, 1/2" air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAUJ100X100-40S, which matches its bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke100 mm
- Port size1/2"
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAUJ100X100-40S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SUJ Adjustable Cylinder SUJ100X100-40S
The AirTAC SUJ100X100-40S is a double-acting, double-rod profile cylinder with an adjustable stroke, meaning an external stop screw allows you to trim the extend stroke by up to 40 mm on-site (usable extend range 60-100 mm). The SUJ series is DISCONTINUED; the direct replacement is the SAUJ100X100-40S, which shares the identical bore, stroke, force, port, and FA/LB mounting.
The SAUJ successor upgrades to current CMSG/DMSG/EMSG sensors, whereas this legacy unit relies on CS1-B/DS1-B switches (indicated by the -S suffix). The external stop screw sets the end position but is not a load lock; you must maintain live air or use an external rod lock for held loads.
Airtac SUJ Adjustable Cylinder SUJ100X100-40S Technical Specifications
| Model | Airtac SUJ Adjustable Cylinder SUJ100X100-40S |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUJ100X100-40S |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/2" |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUJ100X100-40S carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAUJ100X100-40S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUJ Adjustable Cylinder SUJ100X100-40S
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUJ Adjustable Cylinder SUJ100X100-40S Is Used
Variable Depth Pressing
Allows operators to fine-tune the extend stroke by up to 40 mm on-site to accommodate material thickness variations without repositioning the actuator.
Adjustable Diverter Stops
Provides a field-adjustable end position for diverting varying package sizes on a line, letting the stop screw absorb impact and set the exact reach.
Tiered Pallet Positioning
Enables a single cylinder to extend to multiple intermediate heights by limiting the extend stroke on-site, adapting to different pallet stack dimensions.
Replacing the Airtac SUJ Adjustable Cylinder SUJ100X100-40S with the SAUJ100X100-40S
To replace the discontinued SUJ100X100-40S, order the SAUJ100X100-40S for an direct match in bore, stroke, 40 mm adjust window, 1/2" port, and FA/LB mounting. Choose the 40 mm adjust window when your application needs field tuning of the extend stroke between 60 and 100 mm. Note the -S sensor change: legacy CS1-B/DS1-B switches are replaced by CMSG/DMSG/EMSG sensors on the SAUJ. For strokes of 300 mm or longer, verify side-load limits to prevent excessive guide wear.
Replacement checklist
- ✓ Same bore / stroke → SAUJ100X100-40S
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUJ Adjustable Cylinder SUJ100X100-40S FAQ
Yes, the SUJ100X100-40S is discontinued. The direct replacement is the SAUJ100X100-40S, which matches the 100 mm bore, 100 mm stroke, 40 mm adjust window, 1/2" port, and FA/LB mounting. The SAUJ uses current CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B switches.
The external stop screw window is 40 mm, allowing you to trim the extend stroke on-site from the 100 mm maximum down to 60 mm.
