This model is discontinued
AirTAC has phased out the SU series. You can still order this code here: we ship the direct replacement SAUJ100X100-75, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUJ Adjustable Cylinder SUJ100X100-75
The AirTAC Airtac SUJ Adjustable Cylinder SUJ100X100-75 is a double-acting profile-type standard cylinder with a Ø100mm bore and 100mm stroke, 1/2" air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAUJ100X100-75, which matches its bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke100 mm
- Port size1/2"
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAUJ100X100-75
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SUJ Adjustable Cylinder SUJ100X100-75
The AirTAC SUJ100X100-75 is a double-acting double-rod adjustable-stroke profile cylinder, now discontinued. An external stop screw lets you trim the extend stroke by up to 75 mm on-site, giving a usable forward stroke of 25 to 100 mm from the 100 mm nominal maximum. This unit features a 1/2" port, a 25 mm rod, and 29 mm adjustable cushions. The direct replacement is the SAUJ100X100-75, matching the bore, stroke, force, and SC-series FA/LB mounting.
This SKU lacks a magnet (-S omitted) and cannot accept a magnetic switch. The SAUJ upgrade transitions to current CMSG/DMSG/EMSG sensors from the legacy CS1-B/DS1-B switches. The stop screw sets the end position but is not a load lock; use an external rod lock for held loads, as air cushions only decelerate.
Airtac SUJ Adjustable Cylinder SUJ100X100-75 Technical Specifications
| Model | Airtac SUJ Adjustable Cylinder SUJ100X100-75 |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUJ100X100-75 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/2" |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUJ100X100-75 carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAUJ100X100-75 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUJ Adjustable Cylinder SUJ100X100-75
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUJ Adjustable Cylinder SUJ100X100-75 Is Used
Variable Depth Forming Press
Dial in the exact material upset distance on-site by trimming the extend stroke up to 75 mm, avoiding the need to machine custom fixed-length spacers for each new batch.
Adjustable Transfer Diverter
Tune the pusher extension length precisely to accommodate different carton widths on a packaging line without swapping out the entire actuator assembly.
Multi-Position Pallet Stop
Set custom end positions for varying pallet depths by adjusting the external stop screw, providing flexible physical limits without complex multi-position valve plumbing.
Replacing the Airtac SUJ Adjustable Cylinder SUJ100X100-75 with the SAUJ100X100-75
To replace the discontinued SUJ100X100-75, order the direct replacement SAUJ100X100-75, which preserves the 100 mm bore, 100 mm nominal stroke, 75 mm adjust window, 1/2" port, and FA/LB mounting. Choose the 75 mm adjust window if your fixture requires a usable extend stroke between 25 and 100 mm. Because this non-magnetic SKU cannot take a switch, upgrading to the SAUJ allows using current CMSG/DMSG/EMSG sensors instead of legacy CS1-B/DS1-B. For strokes of 300 mm or longer, verify side-load limits to prevent guide wear.
Replacement checklist
- ✓ Same bore / stroke → SAUJ100X100-75
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUJ Adjustable Cylinder SUJ100X100-75 FAQ
Yes, the SUJ100X100-75 is discontinued. The direct replacement is the SAUJ100X100-75, which matches the 100 mm bore, 100 mm stroke, 75 mm adjust window, 1/2" port, and FA/LB mounting. The SAUJ also uses current CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B.
The external stop screw allows you to trim the extend stroke by up to 75 mm on-site, yielding a usable extend stroke of 25 to 100 mm. The stop sets end position but is not a load lock.
