Airtac SULF Front Locking Cylinder SULF100X125S
2. Release mechanisms: Auto-release and Manual-release.
Category: Locking Cylinders , Brand: AirTAC , Series: SULF Series
AirTAC SULF100X125S Front Lock Cylinder Specifications
- Model: SULF100X125S
- Type: Double-acting with mechanical lock
- Bore size: Ø100mm
- Stroke: 125mm
- Operating pressure: 0.1–1.0 MPa
- Lock holding force: 3,200N (at 0.5MPa)
- Lock release pressure: ≥0.15MPa
- Medium: Clean air (Lubricated or non-lubricated)
- Buffer type: Adjustable hydraulic cushion (both ends)
- Mounting style: Standard MF1 (front flange)
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Protection rating: IP54 (standard), IP67 optional
- Weight: 5.8kg ±2%
- Dimensions: 318mm(L) × 125mm(W) × 125mm(H)
Heavy-duty locking cylinder with fail-safe mechanical brake mechanism, featuring dual-position accuracy (±0.5mm). The integrated lock engages automatically during pressure loss, making it ideal for vertical load applications. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 purity standards.
- Automated material handling vertical lifts
- Press machine safety interlocks
- Robotic welding positioner brakes
- Elevator emergency stop systems
- Overhead crane load positioning
Installation note:
Lock engagement requires minimum 0.3s pressure dwell time before motion.
Lubricate through air supply (ISO VG32) if using non-lubricated system.
Avoid side loads exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | SULF100X125S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
