Airtac TSAIL Guided Cylinder TSAIL100X100
$762.35
Regular price
$769.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation requirements:
Requires parallel alignment within 0.1mm/m between guide rods and load path.
Lubricate guide bushings with ISO VG32 hydraulic oil during initial installation.
Maximum side load tolerance decreases by 15% when operating above 60℃.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X100 Guided Rod Cylinder Specifications
- Model: TSAIL100X100
- Type: Double-acting guided rod cylinder
- Bore size: Ø100mm
- Stroke: 100mm (Standard), customizable up to 2000mm
- Guide rod diameter: Ø25mm (Hard chrome-plated)
- Operating pressure: 0.1–0.9 MPa
- Maximum lateral load: 750N (X/Y axes)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: MF1/MF2 flange, MA series foot mounts
- Port size: G3/8 (NPT1/4 optional)
- Temperature range: -10℃ to 80℃
- Piston speed: 50–800 mm/s
- Weight: 15.2kg (Standard stroke)
- Dimensions: 300mm(L) × 150mm(W) × 200mm(H)
- Material: Aluminum alloy barrel, CR12MoV guide rods
- Seal type: NBR + PU combination seals
- ISO certification: 6431/15552 compliant
Heavy-duty guided cylinder with integrated precision linear guides, designed for applications requiring exceptional moment load resistance. Features dual hardened guide rods with adjustable preload mechanism for precise linear motion control. Built-in magnetic piston (D-M9B sensor compatible) allows position feedback integration.
Industrial Applications:
- Automated welding fixture positioning systems
- Die-casting machine core-pulling mechanisms
- Sheet metal bending/punching press tooling
- Automotive assembly line lifting platforms
- Glass manufacturing conveyor alignment systems
Installation requirements:
Requires parallel alignment within 0.1mm/m between guide rods and load path.
Lubricate guide bushings with ISO VG32 hydraulic oil during initial installation.
Maximum side load tolerance decreases by 15% when operating above 60℃.
| Property | Property Value |
|---|---|
| sku | TSAIL100X100 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 100mm |
| Bearing Category | Linear Bearing |
