Airtac TSAIL Guided Cylinder TSAIL100X250
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Rod Cylinder TSAIL100X250 Technical Details
- Model: TSAIL100X250
- Bore size: Ø100 mm
- Stroke: 250 mm
- Mounting type: Fixed/Flange (MF1 pattern optional)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Seal material: NBR + Polyurethane (high wear-resistant)
- Temperature range: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Guide mechanism: Dual linear ball bearings (precision ground)
- Repeat positioning accuracy: ±0.05 mm
- Max lateral load: 2,500 N
- Weight: 12.8 kg (without accessories)
- Dimensions: 550mm(L) × 148mm(W) × 148mm(H) (fully retracted)
- Rod end thread: M20×1.5
- Protection rating: IP40 (standard), IP67 (optional w/rod cover)
Heavy-duty guided cylinder with integrated linear guides, engineered for applications requiring extreme rigidity and anti-rotation stability. The dual-bearing guide structure eliminates rotational play, making it ideal for vertical mounting scenarios. Features chrome-plated piston rod with multi-layer seal system for ≤0.5 mm/sec low-speed stability. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for die casting extraction
- Parallel gripper positioning in robotic palletizing systems
- Sheet metal bending tool guidance
- Glass panel vacuum handling equipment
Installation Tip:
Apply 32# anti-wear lubricating oil to guide rails during assembly.
Maintain 0.5-1mm clearance between cylinder body and machine frame
for thermal expansion compensation. Alignment tolerance ≤0.1mm/m.
| Property | Property Value |
|---|---|
| sku | TSAIL100X250 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <250MM> → <250mm> |
| Bearing Category | Linear Bearing |
