Airtac TSAIL Guided Cylinder TSAIL100X500
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Rod Cylinder TSAIL100X500 Technical Details
- Model: TSAIL100X500
- Type: Double-acting guided rod cylinder
- Bore size: Ø100mm
- Stroke: 500mm (customizable 50-1000mm)
- Operating pressure: 0.05-1.0MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Port size: G3/8 (NPT1/2 optional)
- Guide mechanism: Dual linear ball bearings (pre-loaded)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Mounting: Standard ISO 15552 foot & flange
- Protection rating: IP54 (IP67 with optional kit)
- Weight: 19.8kg ±5%
- Dimensions (L×W×H):
- Total length: 970mm (stroke+base length)
- Guide block width: 158mm
- Overall height: 135mm
- Center-to-center guide distance: 110mm
Precision-guided cylinder engineered for high moment load resistance and anti-rotation stability. Features integrated dual-axis guide rails with preloaded ball bushings (accuracy class P4) that maintain ≤0.05mm lateral play. The staggered seal design combines NBR for static sealing and PU for dynamic sealing, achieving 5 million cycle lifespan at rated load.
- Vertical lifting systems in automotive assembly lines
- Precision glass panel handling robots
- Die-casting machine ejector mechanisms
- Heavy-duty clamping fixtures for CNC machining
- Pharmaceutical tablet press automation
Installation protocol:
Apply Molykote EM-30L grease to guide rails during assembly.
Maximum side load capacity: 2,500N (X/Y axes).
Requires weekly lubrication interval under continuous operation.
| Property | Property Value |
|---|---|
| sku | TSAIL100X500 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 500mm |
| Bearing Category | Linear Bearing |
