Airtac TSAIM Cylinder with Guide Bracket TSAIM100X150S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X150S Guided Rod Cylinder Specifications
- Model: TSAIM100X150S
- Type: Double-acting guided cylinder with linear guide unit
- Bore size: 100mm
- Stroke: 150mm
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Guide mechanism: Precision linear guide rail (stainless steel)
- Mounting style: Front flange (MF1), rear flange (MF2), or side mount
- Port size: G1/2 (ISO standard)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (oil mist lubrication recommended)
- Weight: 12.5kg ±2%
- Dimensions: 400mm(L) × 140mm(W) × 160mm(H)
- Protection rating: IP40 (dust-proof)
- Max lateral load capacity: 3000N
- Repeat positioning accuracy: ±0.05mm
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. Features integrated linear guide rails that eliminate rotational movement, making it ideal for applications requiring exceptional alignment stability. The dual piston design ensures balanced force distribution and minimal deflection during operation.
- Automated assembly lines with high side load requirements
- Material handling systems with vertical lifting
- Precision press-fit operations in electronics manufacturing
- Automotive welding fixture positioning
- Glass panel transfer systems
- Palletizing robots with heavy payloads
Installation guidelines:
Ensure guide rails are parallel to mounting surface within 0.1mm/m tolerance.
Use torque wrench for mounting bolts (spec: 35-40N·m).
Perform lubrication maintenance every 2000 operating hours.
Critical note:
Avoid using in environments with abrasive particles exceeding ISO 4406 18/16/13 cleanliness standard.
Maximum allowable misalignment between cylinder and load: 0.2mm.
| Property | Property Value |
|---|---|
| sku | TSAIM100X150S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
