Airtac TSAIM Cylinder with Guide Bracket TSAIM100X350
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X350 Guided Rod Cylinder Specifications
- Model: TSAIM100X350
- Type: Double-acting guided cylinder with integrated linear bearings
- Bore size: 100mm
- Stroke: 350mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (cushioned)
- Rod diameter: 25mm (chrome-plated steel)
- Guide rod diameter: 20mm x 2 pieces (hardened steel)
- Mounting style: Front flange with precision alignment grooves
- Port size: G3/8 (BSPP thread)
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: NBR + PU hybrid seals
- Protection rating: IP54 (standard), IP67 optional
- Weight: 12.8kg (dry, without accessories)
- Dimensions: 650mm(L) × 152mm(W) × 152mm(H)
- Lubrication: Pre-lubricated (Grease Molykote 33M)
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. The dual guide rod design eliminates rotational movement and reduces piston side-load by 85% compared to standard cylinders. Features wear-compensating guide bushings and integrated mounting datum surfaces for machine tool applications. Requires 5μm filtered air with 1-10mg/m³ oil mist (ISO 8573-1:2010 Class 3-4-1).
- CNC fixture clamping systems
- Die-casting machine ejectors
- Automotive welding robot positioners
- Glass tempering furnace door actuators
- Paper converting equipment
Installation protocol:
Align guide rods within 0.05mm/m parallelism tolerance. Use torque wrench (35-40Nm)
for mounting bolts in cross-pattern sequence. Perform 10-15 dry cycles before load operation.
| Property | Property Value |
|---|---|
| sku | TSAIM100X350 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
