Airtac TSAIM Cylinder with Guide Bracket TSAIM100X50
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X50 Guided Rod Cylinder Technical Details
- Model: TSAIM100X50
- Type: Double-acting guided cylinder with integrated linear guide
- Bore size: Ø100mm (±0.2mm tolerance)
- Stroke: 50mm (standard), customizable up to 500mm
- Mounting style: Square flange with ISO 15552 mounting pattern
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)/-10℃ to 60℃ (FKM seals)
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Guide rail material: Hardened steel with chromium plating (HRC 58-62)
- Seal material: Standard NBR, optional FKM/PU
- Port size: G3/8 (BSPP thread)
- Weight: 5.8kg (empty, without accessories)
- Dimensions: 200mm(L) × 150mm(W) × 120mm(H) (at mid-stroke position)
- Rod end thread: M16×1.5 (male)
- Maximum side load capacity: 1,200N (on guide block)
- Repeat positioning accuracy: ±0.1mm
- IP rating: IP54 (standard), IP67 (optional w/rod cover)
Precision-guided pneumatic cylinder combining piston actuation with hardened linear guides, engineered for applications requiring exceptional anti-rotation stability and moment load resistance. Features dual piston seals with wiper ring for contamination control, and through-rod design for symmetrical force distribution. Optional magnetic piston version (TSAIM100X50-M) available for position feedback.
- Precision press-fit operations in automotive assembly
- Vertical lifting systems with lateral stability requirements
- Glass handling robots requiring vibration-free motion
- PCB depaneling machines needing anti-rotation control
- High-cycle packaging equipment (up to 1,200 cycles/min)
Installation guidelines:
Lubricate guide rails with ISO VG32 hydraulic oil before initial operation.
Maintain ≤0.05mm/m alignment tolerance between cylinder axis and load path.
Use flexible couplings when connecting to rigid mechanisms.
Maximum allowable angular misalignment: 0.5° in pitch/yaw directions.
| Property | Property Value |
|---|---|
| sku | TSAIM100X50 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
