Airtac TSAIM Cylinder with Guide Bracket TSAIM100X500S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X500S Guided Rod Cylinder Specifications
- Model: TSAIM100X500S
- Type: Double-acting guided cylinder with integrated linear bearing
- Bore size: 100mm
- Stroke: 500mm
- Mounting type: Basic profile mounting
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Seal material: NBR/PU combination
- Port size: G3/8 (NPT1/4 optional)
- Guide mechanism: 4-row ball bearing guide with stainless steel rods
- Rod material: Hard chrome-plated steel
- Weight: 8.5kg (dry, without accessories)
- Dimensions: 600mm(L) × 180mm(W) × 140mm(H)
- Max lateral load capacity: 1,500N
- Repeat positioning accuracy: ±0.05mm
- Lubrication: Pre-lubed (Grease retention design)
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. Features dual hardened guide rods with oversized linear bearings for enhanced rigidity and anti-rotation performance. The integrated mounting profile allows direct installation of sensors and accessories. Optimized port design enables 30% faster response compared to standard cylinders.
- Automated assembly line positioning systems
- Material handling with side-mounted tooling
- Press-fit operations in automotive manufacturing
- Vertical lifting mechanisms requiring anti-rotation
- Precision packaging equipment with lateral force demands
Installation note:
Maintain parallel alignment within 0.2mm/m during mounting. Use only with guided rail-compatible couplings.
Apply supplemental lubrication every 500km of travel in high-cycle applications. Avoid side impact loads exceeding 30% of max capacity.
Critical parameters:
Minimum operating pressure 0.08MPa for smooth movement. Maximum piston speed 1,000mm/s.
Requires 5μm filtered air with ISO VG32 equivalent oil mist lubrication in continuous operation.
| Property | Property Value |
|---|---|
| sku | TSAIM100X500S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
