Airtac TSAIM Cylinder with Guide Bracket TSAIM32X300
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM Series Guided Rod Cylinder TSAIM32X300 Technical Details
- Model: TSAIM32X300
- Type: Guided rod double-acting cylinder
- Bore size: 32mm
- Stroke: 300mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Mounting style: Front flange (MF1) / Rear pivot (MP4) optional
- Guide mechanism: Dual linear ball bearings (precision grade C7)
- Port size: M5x0.8 (G1/8 adaptor included)
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Protection rating: IP40 (IP67 with optional wiper kit)
- Weight: 3.8kg ±2% (excluding accessories)
- Dimensions: 495mm(L) × 62mm(W) × 62mm(H) (fully extended)
- Max lateral load: 150N (guide block capacity)
- Piston speed: 50-750mm/s (lubricated condition)
High-rigidity guided cylinder with integrated linear guidance system, featuring zero rotational play and ±0.05mm repeat positioning accuracy. The dual-bearing design eliminates moment load deflection, making it ideal for precision pressing/clamping applications. Includes anti-corrosion treatment for humid environments and comes with magnetic piston for position sensing compatibility.
- Precision die-cutting machine tooling
- PCB depaneling equipment actuators
- Automotive part assembly fixtures
- Glass panel vacuum lifting systems
- Battery module compression testing
Installation guidelines:
Maintain 0.02mm/m alignment tolerance between guide rail and load.
Apply ISO VG32 hydraulic oil for initial lubrication.
Avoid side impact during stroke-end operations.
Recommend using SMC series mufflers for exhaust control.
| Property | Property Value |
|---|---|
| sku | TSAIM32X300 |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
