Airtac UE95A PU Pneumatic Hose UE95A032020020MBR
2、High elasticity: Minimal bending radius enables tight-space routing;
3、Anti-kinking properties: Superior resistance to coiling compared to conventional plastic tubes;
4、Exceptional shape memory: Withstands repeated expansion/contraction cycles;
5、Abrasion resistance: Extended service life in wear-prone environments;
6、Low gas permeability: Reduces leakage and contamination risks;
7、Excellent solvent resistance: Eliminates environmental pollution from fluid migration;
8、Minimal compression set: Maintains critical physical properties under load;
9、Media compatibility: Air/Water.
Category: Compressed Air Tubing , Brand: Airtac , Series: UE95A
AirTAC UE95A PU Pneumatic Hose UE95A032020020MBR Technical Details
- Model: UE95A032020020MBR
- Material: Polyurethane (PU) with textile braid reinforcement
- Inner Diameter: 3.2 mm (±0.1 mm)
- Outer Diameter: 6.0 mm (±0.2 mm)
- Standard Length: 20 meters/coil
- Working Pressure: 0.8 MPa (Max 1.2 MPa intermittent)
- Burst Pressure: ≥4.0 MPa
- Temperature Range: -20℃ to +60℃ (continuous use)
- Bend Radius: 25 mm (minimum recommended)
- Weight: 0.03 kg/m ±5% (0.6 kg total for 20m coil)
- Coil Dimensions: 280mm(W) × 280mm(D) × 120mm(H)
- Color: Blue (RAL 5015)
- Certifications: RoHS compliant, REACH compliant
- Endurance: >1.5 million bending cycles at 90° deflection
Flexible polyurethane hose with spiral reinforcement, designed for high dynamic stress applications. Features excellent kink resistance and memory-free coiling behavior. The smooth inner surface (Ra ≤0.8μm) ensures minimal pressure drop, while the abrasion-resistant outer layer withstands 200,000+ Taber cycles.
- Robotic arm pneumatic tooling
- High-cycle CNC machine tool changers
- Packaging line suction cup systems
- Automated assembly station actuators
- Medical device pneumatic controls
- Food processing equipment (oil-resistant version)
Installation tips:
Use 25-30% slack in installations with continuous motion. Avoid sharp edges -
recommend using protective sleeves when routing through cable carriers.
Maximum permissible tensile load: 15N (static)/8N (dynamic). Compatible with
push-to-connect fittings sized for 3.2mm ID tubing.
| Property | Property Value |
|---|---|
| sku | UE95A032020020MBR |
| Inner Diameter | <2.0mm> |
| Wall Thickness | <0.60mm> |
| Outer Diameter | 3.2mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -40 to 70 |
| Bend Radius | <8mm> |
| Length per Roll | M20 |
| Color | Brown |
