Airtac UE95A PU Pneumatic Hose UE95A032020100MGN
2、High elasticity: Minimal bending radius enables tight-space routing;
3、Anti-kinking properties: Superior resistance to coiling compared to conventional plastic tubes;
4、Exceptional shape memory: Withstands repeated expansion/contraction cycles;
5、Abrasion resistance: Extended service life in wear-prone environments;
6、Low gas permeability: Reduces leakage and contamination risks;
7、Excellent solvent resistance: Eliminates environmental pollution from fluid migration;
8、Minimal compression set: Maintains critical physical properties under load;
9、Media compatibility: Air/Water.
Category: Compressed Air Tubing , Brand: Airtac , Series: UE95A
AirTAC UE95A PU Pneumatic Hose UE95A032020100MGN Technical Specifications
- Full Model Code: UE95A032020100MGN
- Material: Polyurethane (PU) with spiral reinforcement
- Inner Diameter: 3.2 mm ±0.1mm
- Outer Diameter: 6.0 mm ±0.2mm
- Standard Length: 10 meters per coil
- Working Pressure: 0.3-1.0 MPa (Max burst pressure: 5.0 MPa)
- Temperature Range: -20℃ to +60℃ (instantaneous peak 80℃)
- Weight: 0.03 kg/m (Total 0.3 kg per 10m coil)
- Coil Dimensions: Ø300mm × W200mm × H200mm (packaged)
- Color Code: Blue with yellow spiral stripe
- Bend Radius: Min. 25mm (cold state)
- Certification: ROHS compliant, UL-94 HB flammability rating
- Oil Resistance: Excellent (compatible with ISO VG32 hydraulic oil)
Flexible polyurethane tubing with 4-layer spiral reinforcement, designed for high-flex pneumatic applications requiring both durability and kink resistance. Features excellent memory retention and abrasion resistance, with a smooth inner bore to minimize pressure drop. The anti-static formulation prevents dust accumulation in cleanroom environments.
- Robotic arm end-effector pneumatic connections
- High-cycle automated packaging machinery
- CNC tool changer air supply lines
- Food processing equipment (FDA-compliant material)
- Semiconductor wafer handling systems
Installation Guidelines:
Maintain minimum 50mm straight length before/after connectors.
Avoid torsion during routing - maximum twist angle 15°/meter.
Use hose clamps with rounded edges to prevent sheath damage.
- 0.3 MPa: 0.002 bar/m (at 20℃)
- 0.6 MPa: 0.005 bar/m
- 1.0 MPa: 0.012 bar/m
| Property | Property Value |
|---|---|
| sku | UE95A032020100MGN |
| Inner Diameter | <2.0mm> |
| Wall Thickness | <0.60mm> |
| Outer Diameter | 3.2mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -40 to 70 |
| Bend Radius | <8mm> |
| Length per Roll | Stroke 100mm |
| Color | Green |
