Airtac X-AHVFF Manual Valve X-AHVFF0404
AirTAC X-AHVFF0404 Manual Hand Valve Technical Details
- Model: X-AHVFF0404
- Type: 4-way, 3-position manual directional valve
- Port configuration: 4 ports (P, A, B, T) / 3 positions
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Max flow capacity: 850 L/min (Cv=1.5)
- Body material: Aluminum alloy (anodized finish)
- Seal material: HNBR rubber (oil-resistant)
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Manual operation: Lever lock mechanism
- Mounting orientation: Horizontal/Vertical (±15° tolerance)
- Weight: 0.35 kg (0.77 lbs)
- Dimensions: 100mm(L) × 50mm(W) × 40mm(H)
- Port thread depth: 12mm (engagement length)
- Leakage rate: <10 cm³/min at 0.6 MPa
Industrial-grade manual override valve featuring a positive center position lock mechanism. The ergonomic lever design allows precise mid-position control with tactile feedback. Features dual wiper seals for contamination resistance and maintenance-free operation. Compatible with ISO 15407-1 pneumatic standards.
- Emergency override in automated production lines
- Cylinder position manual adjustment during maintenance
- Pneumatic system troubleshooting stations
- Training simulators for hydraulic/pneumatic education
- Mobile equipment manual control interfaces
Operation guidance:
Apply 3-5Nm torque when tightening ports. Lubricate lever pivot
quarterly with ISO VG32 hydraulic oil. Center position requires
audible "click" confirmation for proper engagement.
Avoid side-loading the
control lever. Maximum allowable lateral force: 15N.
Not suitable for vacuum applications.
