Airtac X-AHVFF Manual Valve X-AHVFF0606
AirTAC X-AHVFF0606 Manual Valve Technical Details
- Model: X-AHVFF0606 (4V series manual override valve)
- Type: 4-way/3-position detented manual operator
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Max flow rate: 650 L/min (ANR)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (14℉ to 176℉)
- Weight: 480g ±5% (including accessories)
- Dimensions: 76mm(L) × 52mm(W) × 93mm(H)
- Port thread depth: 12mm (engagement length)
- Operating force: ≤25N (lever actuation)
- Mounting: Direct panel mounting with M5 screws
Industrial-grade manual override valve with positive center position lock, featuring dual-color position indicator (green/red) for visual status confirmation. The 30° ergonomic lever swing requires minimal clearance, while the anti-vibration design maintains position stability under mechanical shock. Compatible with ISO 15407-1 standards.
- Emergency bypass in automated production lines
- Maintenance override for robotic cell safety systems
- Manual mode switching in hydraulic test benches
- Position control in material handling clamp circuits
- Troubleshooting pneumatic logic systems
Installation guidelines:
Apply 2-3Nm torque during port connection. Lubricate pivot points with ISO VG32 oil annually.
For vertical installations, orient exhaust ports downward to prevent debris accumulation.
