Airtac X-AHVFF Manual Valve X-AHVFF0806B
AirTAC X-AHVFF0806B Manual Valve Technical Details
- Full model designation: X-AHVFF0806B
- Valve type: 3/2-way manual push-pull with spring return
- Thread standard: G1/8 (BSPP) with optional NPT1/8 upon request
- Pressure range: 0.05–1.0 MPa (7-145 PSI)
- Flow capacity: 650 NL/min (Cv≈1.2)
- Body material: Anodized aluminum alloy (hard coat 40μm)
- Seal composition: Heat-resistant HNBR (-20℃ to 120℃)
- Actuation force: ≤15N push/pull operation
- Port configuration: 3 ports (P: pressure, A: outlet, R: exhaust)
- Weight: 220g ±5% (without accessories)
- Dimensions: 58mm(L) × 34mm(W) × 72mm(H)
- Mounting options: Panel mount (M4 screw holes) or inline piping
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, ISO 9001 manufactured
Ergonomic manual override valve with tactile position feedback, featuring triple sealing rings for leak-free performance in vacuum and pressure systems. The chrome-plated steel shaft and wear-resistant bushings ensure 500,000+ cycle durability. Includes integrated silencer for exhaust port noise reduction (85dB(A) max).
- Emergency stop override in automated assembly lines
- Pneumatic tool control stations
- Process equipment maintenance bypass systems
- Educational training rigs for fluid power
- Semiconductor wafer handling vacuum circuits
Operational guidance:
Apply silicone-free grease (ISO VG32 equivalent) quarterly for high-cycle applications.
Avoid side-loading during actuation - use center-axis force only.
For vertical installations, orient exhaust port downward to prevent debris ingress.
| Property | Property Value |
|---|---|
| sku | X-AHVFF0806B |
