Airtac X-AHVFF Manual Valve X-AHVFF0808B
AirTAC X-AHVFF0808B Manual Valve Technical Details
- Full model designation: X-AHVFF0808B
- Valve type: 2-position manual shut-off valve (push-pull operation)
- Port configuration: 8 ports (4 in/4 out)
- Port thread size: PT1/4 (G1/4 optional)
- Maximum operating pressure: 0.9 MPa
- Minimum operating pressure: 0.05 MPa
- Flow capacity: 350 NL/min (ANR)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature tolerance: -20℃ to 80℃
- Weight: 350g ±5%
- Dimensions: 55mm(W) × 28mm(H) × 100mm(L)
- Surface finish: Electrophoretic coating (salt spray resistant)
- Manual actuation force: ≤5N
- Leakage rate: ≤3 bubbles/min (ISO 6953-1 test)
Multi-circuit manual override valve featuring color-coded position indicators (green=open/red=closed) and positive detent mechanism. The ergonomic toggle design allows single-finger operation with tactile feedback. Integrated O-ring groove design prevents seal extrusion under cyclic loading.
- Emergency shutdown systems in pneumatic production lines
- Sectional isolation during maintenance of industrial machinery
- Pressure regulation in compressed air distribution manifolds
- Manual override for automated assembly equipment
- Educational pneumatic training stations
Installation protocol:
Mount in accessible locations with 30mm clearance for hand operation.
Lubricate threads with PTFE tape (not included). Perform monthly
functional checks under 0.4MPa pressure. Avoid side-loading
during actuation to prevent stem misalignment.
