Airtac X-AHVFF Manual Valve X-AHVFF1010B
AirTAC X-AHVFF1010B Manual Valve Technical Details
- Model: X-AHVFF1010B
- Type: 3/2-way manual push-pull valve (Normally Closed)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–0.9 MPa
- Flow coefficient (Cv): 1.2
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Ambient temperature: -20℃ to 80℃
- Actuation force: 25N max
- Mounting options: Base plate or panel mounting
- Weight: 600g ±5%
- Dimensions: 101mm(L) × 46mm(W) × 38mm(H)
- Port thread depth: 13mm (male thread)
- Leakage rate: <10 cm³/min at 0.5 MPa
- Protection rating: IP54 (standard configuration)
Mechanical manual override valve with positive position lock mechanism, featuring ergonomic knob design for precise manual control in pneumatic systems. The chrome-plated actuator shaft ensures smooth operation and corrosion resistance. Designed for systems requiring manual intervention without electrical power, with visual position indicator window for status confirmation.
- Emergency override in automated production lines
- Maintenance bypass in hydraulic/pneumatic test benches
- Safety isolation in semiconductor manufacturing equipment
- Manual control in prototype machinery development
- Educational training systems for fluid power
Installation guidelines:
Mount in accessible locations with minimum 50mm clearance around actuator.
Apply thread sealant (LOCTITE 5452 recommended) on port threads.
Perform monthly lubrication of sliding parts with silicone grease (ISO VG 10).
