Airtac X-AHVFF Manual Valve X-AHVFF1210B
AirTAC X-AHVFF1210B Manual Valve Technical Details
- Model: X-AHVFF1210B
- Type: 3-position closed center, 4-way manual valve
- Port configuration: 4 ports (P, A, B, R) / 3 positions
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.2–0.8 MPa
- Max flow rate: 750 L/min (ANR)
- Body material: Aluminum alloy (anodized finish)
- Seal material: HNBR rubber (-20℃ to 80℃)
- Operating temperature: -20℃ to 80℃
- Weight: 350g ±5%
- Dimensions: 65mm(L) × 40mm(W) × 85mm(H)
- Mounting style: Sub-base or direct piping
- Manual override: Rotary lever with position lock
- Pressure resistance: 1.2 MPa burst pressure
Industrial-grade manual control valve featuring a rugged rotary mechanism with tactile position feedback. The hardened stainless steel shaft and wear-resistant seals ensure >500,000 cycle durability. Center closed position blocks all ports for safety lockout. Compatible with ISO 15407-1 standard sub-bases.
- Emergency stop circuits in production lines
- Manual override for automated pneumatic systems
- Mobile hydraulic/pneumatic equipment control
- Safety interlocks in press machinery
- Training rigs for fluid power education
Installation guidelines:
Lubricate thread ports with PTFE tape during assembly.
For vertical mounting, ensure exhaust ports face downward to prevent debris accumulation.
Maximum recommended tightening torque: 15 N·m.
| Property | Property Value |
|---|---|
| sku | X-AHVFF1210B |
