Airtac X-AHVFS Hand Valve X-AHVFS0802
$8.90
Regular price
$16.40
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-AHVFS0802
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-AHVFS0802 Manual Hand Valve Specifications
- Model: X-AHVFS0802
- Type: 3/2-way manual push-pull valve (spring return)
- Port size: PT1/4 (G1/8 adaptor optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Manual actuation force: 30-50N
- Weight: 350g ±5% (including fittings)
- Dimensions: 75mm(L) × 45mm(W) × 40mm(H)
- Body material: Anodized aluminum alloy
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Flow capacity: CV 0.25 (at 0.5 MPa)
- Port thread depth: 10mm (full engagement)
- Protection rating: IP40 (dust protected)
Ergonomic manual override valve with tactile position feedback, featuring a corrosion-resistant body and visible status indicator window. The dual-spring return mechanism ensures positive shutoff in neutral position. Compatible with ISO 15407-1 standard pneumatic systems.
Typical Applications:
- Emergency stop override in automated assembly lines
- Maintenance bypass in plastic injection molding machines
- Manual control in pneumatic testing stations
- Actuator positioning in semiconductor handling equipment
- Mobile hydraulic system venting controls
Operation guidance:
Apply firm downward pressure (until audible click) for full flow activation.
For partial flow control, rotate knob 90° counterclockwise before pulling.
Lubricate pivot points every 50,000 cycles using ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | X-AHVFS0802 |
