Airtac X-AHVFS Hand Valve X-AHVFS0802B
AirTAC X-AHVFS0802B Manual Valve Technical Details
- Model: X-AHVFS0802B
- Type: 2-position 3-way manual valve (push-pull operation)
- Port configuration: 3/2-way (normally closed)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Flow capacity: 650 L/min (ANR)
- Body material: Die-cast aluminum alloy (hard anodized)
- Seal material: HNBR rubber (-20℃ to 120℃)
- Actuation force: 35N max
- Weight: 340g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 52mm(H)
- Thread engagement depth: 12mm min
- Operating temperature: -20℃ to 80℃ (with silicone seals optional for 150℃)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Shock resistance: 100m/s² (3 axes)
Robust manual override valve with precision flow control, featuring double-seal structure for leak-free operation. The ergonomic knob design allows gloved operation with positive tactile feedback. Integrated locking mechanism prevents accidental position changes. Compatible with ISO 15407-1 standards.
- Emergency shutdown systems in pneumatic circuits
- Manual override for automated production line jigs
- Process control in food-grade pneumatic systems
- Mobile hydraulic equipment maintenance bypass
- Semiconductor manufacturing tooling
Installation guidelines:
Mount in accessible locations with minimum 50mm clearance for hand operation.
Lubricate threads with PTFE tape (do not exceed 2 wraps).
Perform monthly visual inspections for seal wear in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | X-AHVFS0802B |
