Airtac X-AHVFS Hand Valve X-AHVFS1002
AirTAC X-AHVFS1002 Manual Valve Technical Details
- Model: X-AHVFS1002
- Type: 2-position 5-port manual valve (spring return)
- Port configuration: 1/4" BSPP (G1/4)
- Operating pressure range: 0.2–0.8 MPa
- Max flow capacity: 750 L/min (ANR)
- Actuation force: ≤5 N·m (lever torque)
- Valve body material: Anodized aluminum alloy
- Seal material: HNBR (high-temp nitrile)
- Temperature tolerance: -20℃ to 80℃
- Weight: 320g ±5g
- Dimensions: 82mm(L) × 38mm(W) × 53mm(H)
- Port thread depth: 10.5mm (full engagement)
- Leakage rate: <0.1 mL/min @ 0.6 MPa
- Mounting options: Panel mount with M5 screws (4x)
Industrial-grade manual override valve featuring bi-directional flow control with visual position indicator. Designed for systems requiring manual intervention without pneumatic/electrical supply. Robust construction withstands vibration and features corrosion-resistant coating for harsh environments.
- Emergency shutdown systems in production lines
- Maintenance bypass in automated assembly machines
- Pneumatic circuit debugging & troubleshooting
- Training simulators for fluid power systems
- Mobile equipment requiring manual override
Installation guidelines:
Align flow direction arrow with system requirements. Apply 242 Loctite®
on mounting screws. For horizontal mounting, ensure lever rotates freely
within 120° arc. Use filtered air (≤40μm) to prevent seal abrasion.
| Property | Property Value |
|---|---|
| sku | X-AHVFS1002 |
