Airtac X-AHVSF Handle Valve X-AHVSF0108
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
AirTAC X-AHVSF0108 Manual Valve Technical Details
- Model: X-AHVSF0108 (Full series: X-AHVSF0104 to X-AHVSF0208)
- Type: 2-position manual directional valve (spring return)
- Port configuration: 3/2-way (3 ports, 2 positions)
- Port size: PT1/8 (BSPP thread standard)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 350 NL/min (ANR)
- Valve body material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber) standard, optional FKM
- Ambient temperature range: -5℃ to 80℃
- Operating force: ≤20N lever actuation
- Weight: 300g ±5% (including fittings)
- Dimensions: 60mm(L) × 40mm(W) × 25mm(H)
- Port orientation: Side entry, vertical exhaust
- Mounting options: Panel mount with M5 fasteners
- Protection rating: IP40 (dust-protected)
Robust manual override valve featuring chrome-plated brass construction for corrosion resistance in humid environments. The ergonomic toggle lever allows quick manual intervention with positive tactile feedback. Includes built-in flow adjustment with ±15% flow rate tuning capability via rotary knob. Requires 5μm filtered compressed air (ISO 8573-1:2010 Class 4.4.3).
- Emergency stop override in automated assembly lines
- Maintenance bypass for pneumatic cylinder positioning
- Manual mode switching in packaging machinery
- Process testing in semiconductor manufacturing equipment
- Educational pneumatic training systems
Installation guidelines:
Mount in accessible locations with ≥15mm clearance for lever operation.
Lubricate pivot points with ISO VG32 hydraulic oil quarterly.
For horizontal piping systems, install exhaust port downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0108 |
