Airtac X-AHVSF Handle Valve X-AHVSF0108B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
AirTAC X-AHVSF0108B Manual Valve Technical Details
- Full model: X-AHVSF0108B
- Valve type: 3-position manual shut-off valve (lockable lever)
- Port configuration: 1/4" BSPP female threads (G1/4)
- Max working pressure: 12 bar (174 psi)
- Pressure range: 0.2-12 bar (2.9-174 psi)
- Flow capacity: 450 NL/min (Cv≈0.35)
- Body material: Anodized aluminum alloy (black finish)
- Seal material: HNBR (hydrogenated nitrile) for oil resistance
- Operating temperature: -20℃ to 80℃ (with intermittent peaks to 100℃)
- Weight: 320g ±5% (including accessories)
- Dimensions: 56mm(W) × 56mm(H) × 100mm(L)
- Mounting: Panel mount with M5 threaded holes (spacing 40mm)
- Leakage rate: <3 bubbles/min under 7 bar pressure (ISO 6952)
Industrial-grade manual override valve with positive locking mechanism and 90° lever rotation. Features dual-stage sealing with dust wiper for harsh environments. The ergonomic lever design allows gloved operation. Compatible with ISO 15407-1 standard pneumatic systems.
- Emergency stop circuits in assembly line equipment
- Maintenance isolation in plastic injection molding machines
- Manual override for automated packaging systems
- Process control in semiconductor manufacturing tools
- Safety shut-off in compressed air distribution lines
Installation guidelines:1. Use backup wrench on hex flats during port connection
2. Apply 3-5Nm torque for port sealing
3. Keep lever rotation plane clear of obstructions
4. Recommended air filtration: 25μm with auto-drain
| Property | Property Value |
|---|---|
| sku | X-AHVSF0108B |
