AirTAC X-AHVSF0208 Manual Valve Technical Details
- Model: X-AHVSF0208
- Type: 2-position 3-way manual push-pull valve
- Port configuration: 3 ports (P, A, R) / 2 positions
- Port thread size: PT1/8 (BSPP) with NPT optional
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 350 L/min (ANR)
- Body material: Reinforced PBT resin with 30% glass fiber
- Seal material: Heat-resistant NBR (70±5 Shore A)
- Operating temperature: -5℃ to 80℃ (no ice formation)
- Manual operation force: ≤15N
- Weight: 280g ±5%
- Dimensions: 85mm(L) × 40mm(W) × 65mm(H)
- Mounting: Direct panel mounting with M5 screw holes
- Pressure resistance: 1.5 MPa burst pressure
Compact manual valve featuring tactile feedback and positive detent mechanism for precise flow control. The ergonomic lever design allows single-finger operation with dust-resistant construction (IP54 equivalent). Includes built-in silencer and status indicator window. Compatible with ISO 15407-1 standards for pneumatic systems.
- Emergency stop circuits in production lines
- Manual override in automated assembly systems
- Air supply control for CNC machine tools
- Pneumatic training equipment in technical schools
- Material handling system bypass controls
Installation guidance:
Maintain horizontal mounting position (±15° tolerance). Apply 0.5-1.2Nm torque
during port connection. For vertical mounting, use optional bracket AHB-202.
Lubricate seals with ISO VG32 pneumatic oil if unused >6 months.
Critical note:
Not suitable for vacuum applications or aggressive gases.
Always bleed residual pressure before servicing. Replace seals every
500,000 cycles or 3 years (whichever comes first).
