Airtac X-AHVSF Handle Valve X-AHVSF0208B
AirTAC X-AHVSF0208B Manual Valve Technical Details
- Model: X-AHVSF0208B
- Type: 2-position manual shut-off valve
- Port configuration: 2 ports, 1 position (L-type flow path)
- Thread standard: PT1/4 (BSPP) female threads
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Body material: Anodized aluminum alloy (black oxide finish)
- Seal material: HNBR rubber (high nitrile)
- Operating temperature: -10℃ to 80℃ (no ice formation)
- Flow coefficient (Cv): 0.65
- Actuation torque: ≤1.2 N·m
- Weight: 285g ±5g
- Dimensions: 76mm(L) × 38mm(W) × 94mm(H)
- Surface treatment: Chromate conversion coating
- Port alignment: 90° orthogonal configuration
Heavy-duty manual isolation valve featuring positive-locking lever mechanism with 90° rotation arc. The ergonomic handle includes tactile position indicators and anti-slip grooves. Features bubble-tight shut-off with zero leakage Class IV sealing (ISO 12238). Compatible with compressed air and inert gases.
- Pneumatic system maintenance lockout/tagout
- Production line pressure isolation during tooling changes
- Emergency shutdown in material handling systems
- Pressure vessel safety isolation
- Process control bypass configurations
Installation guidelines:
Mount in accessible locations with full lever rotation clearance (120mm radius).
Apply pipe sealant only on male threads, avoiding contamination of valve seat.
Periodic lubrication of pivot point recommended (use ISO VG32 hydraulic oil).
| Property | Property Value |
|---|---|
| sku | X-AHVSF0208B |
