Airtac X-AHVSF Handle Valve X-AHVSF0308B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
AirTAC X-AHVSF0308B Manual Valve Technical Details
- Full Model Code: X-AHVSF0308B
- Valve Type: 3-position (Open/Close/Exhaust) detent-type manual valve
- Port Configuration: 3 ports (P: Pressure, A: Output, R: Exhaust)
- Thread Standard: G1/8 (ISO228) with metal-to-metal sealing
- Operating Pressure: 0.05–1.0 MPa (7–145 PSI)
- Flow Capacity: 750 NL/min (Cv=1.2)
- Body Material: Anodized aluminum alloy (AL6063-T5)
- Seal Material: High-grade HNBR (Hydrogenated Nitrile) for chemical resistance
- Operating Temperature: -20℃ to 80℃ (continuous duty)
- Manual Actuation: Stainless steel lever with 90° rotation angle
- Weight: 285g ±5g (including all fittings)
- Dimensions: 58mm(L) × 42mm(W) × 72mm(H) (body only)
- Mounting: Panel mount with M4 threaded holes (4x)
- Leakage Rate: <0.1 NmL/min at 0.5 MPa
- Cycle Life: 1,000,000 operations minimum
Industrial-grade manual override valve with positive position locking mechanism. Features a dual-chamber design for smooth operation under vacuum or pressure conditions. The ergonomic lever incorporates tactile feedback with 30N±5 actuation force. Compatible with ISO 15407-1 standards for pneumatic components.
- Emergency shut-off in automated production lines
- Maintenance bypass in hydraulic/pneumatic systems
- Process control override in semiconductor fab equipment
- Manual mode activation for robotic assembly units
- Educational training systems for fluid power labs
Installation Guidelines:
Apply 5-7Nm torque during port connection. For vertical mounting,
orient exhaust port downward. Use lock nut (M4, included) for
panel fixation. Lubricate pivot point annually with ISO VG32 oil.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0308B |
