Airtac X-AHVSF Handle Valve X-AHVSF0310B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
AirTAC X-AHVSF0310B Manual Valve Technical Details
- Full model code: X-AHVSF0310B
- Valve type: 3-position manual selector valve (push-pull locking mechanism)
- Port configuration: 3/2-way (3 ports, 2 positions)
- Thread standard: G1/8 (ISO228-1 compliant)
- Operating pressure range: 0.05-0.9 MPa
- Maximum flow rate: 350 NL/min (ANR)
- Body material: Aluminum alloy (hard anodized surface)
- Seal material: Fluororubber (FKM) for high temperature resistance
- Ambient temperature range: -10℃ to 80℃
- Operating force: ≤15N (at 0.6MPa)
- Weight: 320g ±5g
- Dimensions: 72mm(L) × 48mm(W) × 38mm(H)
- Mounting options: Panel mounting (with integrated bracket) or inline piping
- Leakage rate: ≤5 bubbles/min (ISO 6952 test standard)
Heavy-duty manual override valve designed for pneumatic system maintenance and emergency control. Features zero-power operation with tactile position feedback and dust-resistant toggle mechanism. The ergonomic knob allows gloved operation, with color-coded position indicators (red/green) for clear status confirmation.
- Production line emergency stop systems
- Pneumatic cylinder manual override control
- Compressed air system maintenance bypass
- Training simulators for industrial automation
- Mobile hydraulic/pneumatic hybrid machinery
Installation guidelines:
For optimal performance, install with downward-facing exhaust port to prevent
debris accumulation. Apply thread sealant (PTFE tape recommended) on pipe connections.
Perform monthly lubrication of the sliding mechanism using ISO VG32 hydraulic oil.
• AirTAC X-ASM08 mounting bracket series
• X-APV01 protective cover kit
• X-APL2001 position lock collar (anti-vibration)
| Property | Property Value |
|---|---|
| sku | X-AHVSF0310B |
