Airtac X-AHVSF Handle Valve X-AHVSF0312B
AirTAC X-AHVSF0312B Manual Valve Technical Specifications
- Model: X-AHVSF0312B
- Type: 3-position (Closed/Center/Exhaust) detented manual valve
- Port configuration: 3-way, 3-position
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow capacity: 1000 NL/min
- Actuation type: Rotary knob with position lock
- Body material: Anodized aluminum alloy
- Seal material: HNBR/NBR (dual-seal design)
- Temperature range: -10℃ to 80℃
- Weight: 0.85 kg (±3%)
- Dimensions: 98mm(L) × 68mm(W) × 72mm(H)
- Mounting: Sub-base compatible (ISO 15407-1 standard)
- Leakage rate: <0.1 cm³/min at 0.5 MPa
- Operating torque: ≤1.2 N·m
Industrial-grade manual valve with positive center detent mechanism, featuring wear-resistant composite seals and corrosion-resistant coating. The dual-ported exhaust design ensures rapid cylinder response in pneumatic systems. Integrated dust shield prevents particulate ingress in harsh environments.
- Emergency override in automated production lines
- Pneumatic system manual control stations
- Material handling equipment safety circuits
- Test bench pressure regulation systems
- Hydraulic system pilot controls
Maintenance note:
Apply silicone-free lubricant (ISO VG32 grade) quarterly to rotating mechanism.
Ensure detent ball spring tension remains 3.5-4.2N during maintenance checks.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0312B |
