Airtac X-AHVSF Handle Valve X-AHVSF0410B
AirTAC X-AHVSF0410B Manual Valve Technical Details
- Model: X-AHVSF0410B
- Type: 4-position 5-way manual directional valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Flow capacity: 850 NL/min (ANR)
- Valve body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) standard / FKM (Viton) optional
- Operating temperature: -5℃ to 80℃ (with NBR seals)
- Weight: 0.52 kg (1.15 lbs)
- Dimensions: 80mm(L) × 40mm(W) × 40mm(H)
- Mounting style: Sub-base or direct piping
- Actuation force: ≤5 N (rotary knob operation)
- Position indication: Visual arrow markers
Industrial-grade manual override valve featuring positive center position locking and tactile feedback. The chrome-plated brass rotary knob provides corrosion resistance in humid environments. Designed for emergency override scenarios or maintenance operations in automated systems. Requires ISO 8573-1:2010 Class 3 compressed air quality.
- Production line emergency stop/reset systems
- Pneumatic cylinder manual position resetting
- Tooling fixture pressure regulation
- Mobile equipment air circuit isolation
- Training simulators for pneumatic system education
Installation best practice:
Apply thread sealant (PTFE tape recommended) on port connections.
For vertical mounting, ensure exhaust ports face downward to prevent
debris accumulation. Perform monthly knob lubrication with silicone grease.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0410B |
