Airtac X-AHVSF Handle Valve X-AHVSF0602B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
AirTAC X-AHVSF0602B Manual Valve Technical Profile
- Full model designation: X-AHVSF0602B
- Valve type: 3/2-way manual reset with mechanical lock
- Port configuration: 1/4" BSPP (G1/4) female threads
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Flow capacity: 850 NL/min (Cv=1.2)
- Actuation force: ≤3.5N with ergonomic lever design
- Body material: Anodized aluminum alloy (hard coat 25μm)
- Seal compounds: HNBR main seals + FKM secondary wipers
- Ambient temperature tolerance: -15℃ to 80℃ (derate above 50℃)
- Weight: 280g ±5% (including mounting hardware)
- Dimensional package: 68mm(L) × 34mm(W) × 42mm(H)
- Mounting options: Panel mount with M4 fasteners or DIN rail adaptable
- Pressure test certification: ISO 6952-1 compliant
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
Industrial-grade manual override valve featuring tactile position feedback and double-seal security. The X-AHVSF0602B combines 300,000-cycle durability with IP67 environmental protection, engineered for systems requiring manual intervention without compromising pneumatic integrity. Requires 5-40μm filtration and ISO VG32-grade lubricant compatibility.
- Emergency stop circuits in plastic injection molding machines
- Maintenance bypass in robotic welding cell pneumatics
- Process line configuration switching for food packaging systems
- Manual mode activation in semiconductor handling equipment
- Training rigs for vocational pneumatics education
Commissioning protocol:
Perform 5-10 full actuation cycles before system pressurization.
Ensure lever travel path remains unobstructed (±15° arc clearance required).
Annual seal replacement recommended in high-cyclone dust environments.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0602B |
