Airtac X-AHVSF Handle Valve X-AHVSF0801B
$8.90
Regular price
$16.40
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-AHVSF0801B
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-AHVSF0801B Manual Valve Technical Details
- Model: X-AHVSF0801B
- Type: 3/2-way manual push-pull valve (spring return)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Flow capacity: 800 L/min (Cv=1.3 at 0.5 MPa)
- Body material: Anodized aluminum alloy (hard coating)
- Seal material: HNBR rubber (oil/heat resistant)
- Temperature range: -20℃ to 80℃ (fluid/ambient)
- Actuation force: ≤15N push-pull operation
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 55mm(H)
- Port orientation: Axial inlet/outlet configuration
- Mounting options: Panel mount (with locknut) or inline
- Protection rating: IP54 (dust/water splashes)
Ergonomic manual override valve with visual position indicator (red pushbutton status window). Features zero-leakage poppet design and anti-vibration structure, optimized for high-cycle manual control in industrial environments. Compatible with ISO 15407-1 standards.
Typical Applications:
- Emergency stop/purge functions in CNC machines
- Manual mode switching on automated assembly lines
- Maintenance bypass control for pneumatic systems
- Mobile hydraulic test bench configurations
- Process equipment manual override systems
Installation guidelines:
Lubricate threads with PTFE tape during installation. For vertical mounting,
ensure exhaust port faces downward to prevent debris accumulation.
Maximum torque: 15N·m for port connections.
Fluid Compatibility:
Compressed air (lubricated/non-lubricated), inert gases.
Not recommended for steam, corrosive media, or particle-laden flows above ISO 4406 18/16/13.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0801B |
