Airtac X-AHVSF Handle Valve X-AHVSF0802B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
AirTAC X-AHVSF0802B Manual Valve Specifications
- Model: X-AHVSF0802B
- Type: 2-position manual shut-off valve (lever-operated)
- Port size: PT1/4 (G1/8 optional)
- Max operating pressure: 1.0 MPa
- Flow capacity: 700 NL/min
- Actuation force: ≤3.5 N
- Weight: ~220g (with accessories)
- Dimensions: 50mm(L) × 42mm(W) × 76mm(H)
- Body material: PA66 reinforced nylon
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 80℃
- Protection rating: IP67 (dust/water resistant)
- Port orientation: Axial flow design
Robust manual isolation valve featuring positive visual position indication and tool-free installation. The ergonomic lever design allows single-finger operation with tactile feedback, while the self-lubricating stem ensures smooth actuation over 100,000+ cycles. Compatible with air, inert gases, and vacuum systems.
- Emergency line shut-off in production machinery
- Modular pneumatic system maintenance isolation
- Vacuum chamber pressure control systems
- CNC machine tool auxiliary circuit control
- Semiconductor manufacturing gas lines
Installation note:
Arrow markings indicate flow direction - ensure proper alignment.
Apply 2-3Nm torque during port connection to prevent seal deformation.
For vertical mounting, orient lever movement parallel to floor.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0802B |
