Airtac X-AHVSF Handle Valve X-AHVSF0803B
AirTAC X-AHVSF0803B Manual Valve Technical Specifications
- Full model code: X-AHVSF0803B
- Valve type: 3/2-way manual push-pull valve (spring return)
- Thread standard: G1/8 (BSPP parallel thread)
- Pressure range: 0.05–1.0 MPa (7–145 PSI)
- Flow capacity: 550 NL/min (Cv=0.45)
- Body material: Anodized aluminum alloy (hard coat)
- Seal composition: HNBR hydrogenated nitrile (oil/heat resistant)
- Operating temp: -10℃ to 80℃ (14°F to 176°F)
- Ambient humidity: 35–95% RH (non-condensing)
- Actuation force: 3.5kgf (manual lever effort)
- Weight: 480g ±5% (with accessories)
- Dimensions: 80mm(L) × 30mm(W) × 30mm(H)
- Port positions: 3 ports (P: pressure, A: outlet, R: exhaust)
- Mounting: Direct panel mounting (M5 screw points)
Robust manual override valve with tactile position feedback, featuring dual-color position indicator (red/green band) for visual status confirmation. The ergonomic lever design allows single-finger operation with positive detent positions. Includes built-in silencer for exhaust port noise reduction (62 dB(A) max). Compatible with ISO 8573-1:2010 Class 3 compressed air.
- Emergency override in automated production lines
- Maintenance bypass in plastic injection molding machines
- Manual control station for pneumatic conveyor systems
- Safety lockout/tagout procedures in press machinery
- Educational pneumatic training equipment
Operation guidance:
Push lever downward for circuit activation (P→A flow), pull upward to reset (A→R exhaust).
Apply silicone-free grease (ISO VG32 equivalent) quarterly for smooth operation.
