Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT1001
AirTAC X-APBT1001 Full Brass Threaded Straight Tee Specifications
- Model: X-APBT1001
- Type: Equal tee with 100% brass construction
- Thread standard: BSPP (G thread) / NPT optional
- Port configuration: 1/8" female threads (3 ports)
- Pressure rating: 0.3-1.0 MPa (43.5-145 PSI)
- Proof pressure: 1.5 MPa (217.5 PSI)
- Burst pressure: ≥3.0 MPa (435 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Surface treatment: Electro-polished anti-oxidation coating
- Weight: 28g ±1g
- Dimensions: 25mm(L) × 25mm(W) × 25mm(H) ±0.5mm
- Flow coefficient (Cv): 0.12
- Certification: RoHS compliant
Precision-machined brass tee connector featuring triple-directional flow control with zero dead space design. The hexagonal body allows secure wrench tightening (14mm AF). Electroless nickel plating provides corrosion resistance in humid environments. Compatible with air, inert gases, and non-flammable hydraulic fluids.
- Pneumatic circuit branching in automation equipment
- Instrumentation gas distribution systems
- Compressed air networks for packaging machinery
- Hydraulic test bench configurations
- Industrial robot end-effector pneumatic lines
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (Grade DIN 3852-C).
Tighten to 12-15 N·m torque using calibrated wrench.
Avoid overtightening - brass threads deform at 20 N·m+.
| Property | Property Value |
|---|---|
| sku | X-APBT1001 |
