Airtac X-APE Connector - T Tee X-APE10
AirTAC X-APE10 T-Type Tee Fitting Specifications
- Model: X-APE10
- Type: T-shaped tee connector (metal-to-metal seal)
- Thread standard: Metric (M5×0.8) / Optional BSPP (PT1/8)
- Material: Brass with nickel plating (CuZn39Pb3)
- Pressure rating: 0.05–1.0 MPa (7–145 psi)
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal type: Precision machined metal sealing surface + auxiliary NBR O-ring
- Surface roughness: Ra ≤1.6μm (sealing areas)
- Weight: 28±2g
- Dimensions: 20mm(L) × 20mm(W) × 20mm(H) (main body)
- Port-to-port distance: 10mm (center alignment)
- Thread engagement depth: 5mm minimum
- Protection rating: IP40 (dust protected)
High-density forged brass tee connector featuring dual sealing technology combining metal-to-metal contact and elastomer backup. The 60° cone seat design ensures leak-free performance under vibration, while the hexagonal body allows 360° positioning flexibility. Anodized identification marks prevent installation errors.
- Modular pneumatic manifold assemblies
- Robotic end-effector air distribution
- CNC machine tool coolant line junctions
- Medical gas panel distribution systems
- Semiconductor fab equipment plumbing
Installation protocol:
Apply 1-2 drops of pneumatic sealant (viscosity ≤50 cSt) on threads before assembly.
Tighten to 1.2-1.5 N·m torque using crowfoot wrench. Avoid overtightening beyond 2.0 N·m
to prevent seat deformation. Perform pressure test at 1.25× operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APE10 |
