Airtac X-APE Connector - T Tee X-APE12
$3.79
Regular price
$11.29
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APE12
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APE T-Type Tee Connector X-APE12 Technical Details
- Model: X-APE12
- Type: Brass T-style pneumatic tee connector
- Material: Lead-free brass with nickel plating
- Thread standard: Metric (M5) & PT1/8 dual-standard ports
- Port configuration: 3-way equal diameter (12mm port spacing)
- Max working pressure: 1.5 MPa (217 psi)
- Pressure range: 0.05-1.5 MPa
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Surface roughness: Ra ≤3.2μm
- Weight: 35g ±2g
- Dimensions: 40mm(L) × 20mm(W) × 20mm(H)
- Thread engagement depth: 8mm minimum
- Torque specification: 1.5-2.0 N·m
Precision-engineered brass tee connector with dual-standard threading, designed for stable flow distribution in compact pneumatic systems. Features 360° rotatable ports for flexible piping layouts and leak-proof elliptical seal design. Compatible with ISO 15407-1 standard components.
Typical Applications:
- Branch line creation in FRL (Filter-Regulator-Lubricator) units
- Vacuum circuit manifold connections
- Multi-axis pneumatic tool manifolding
- Medical gas line distribution systems
- Robotic end-effector air supply splitting
Installation note:
Apply 2-3 wraps of PTFE tape on male threads (Type B only).
Avoid overtightening - stop rotation when 1.5mm thread remains visible.
For vertical mounting, position main flow port downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | X-APE12 |
