Airtac X-APG Adapter - Reducing Straight Fitting X-APG108
AirTAC X-APG108 Reducing Straight Connector Technical Details
- Model: X-APG108
- Type: Threaded reducing union (male to female)
- Material: Stainless steel (SUS303) with electropolished finish
- Inlet thread: PT1/8 (G1/8)
- Outlet thread: PT1/4 (G1/4)
- Pressure rating: 0.1-1.0 MPa (14.5-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 15.2g ±0.5g
- Dimensions: 25mm(L) × 12mm(OD outlet end) × 6mm(OD inlet end)
- Surface roughness: Ra ≤0.8μm
- Seal material: HNBR O-ring (high nitrile)
- Vibration resistance: ≤10Hz @ 1.5mm amplitude
- Corrosion resistance: 96hr salt spray test passed
Precision-machined stepped connector enabling secure transitions between different pneumatic line sizes. Features dual-axis alignment grooves for anti-rotation during installation. Electropolished interior minimizes flow turbulence and particle retention. Rated for 500,000+ connection cycles.
- Branch line diameter reduction in FRL (Filter-Regulator-Lubricator) units
- Compact pneumatic circuit conversions
- Medical gas line adapters
- Industrial robot tool changer interfaces
- Vacuum system component integration
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Torque limit: 1.2-1.5N·m. Perform pressure test at 1.25x
working pressure after installation. Avoid cross-threading
using alignment marks.
