Airtac X-APG Adapter - Reducing Straight Fitting X-APG1206
AirTAC X-APG1206 Reducer Straight Connector Technical Details
- Model: X-APG1206 (Metric Series)
- Type: Double-ended male threaded reducer
- Material: Brass (Nickel-plated surface)
- Thread Standards: G1/8 (Port A) to G1/4 (Port B)
- Max Working Pressure: 1.5 MPa (217 psi)
- Proof Pressure: 3.0 MPa (435 psi)
- Burst Pressure: ≥6.0 MPa (870 psi)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: NBR (Nitrile Rubber)
- Surface Roughness: Ra ≤1.6μm
- Weight: 18.5g ±0.5g
- Dimensions: 28mm(Length) × 16mm(Width) × 16mm(Height)
- Hex Size: 12mm (Port A) / 17mm (Port B)
- Compliance: ISO 1179-1 standard
Precision-machined adapter for transitioning between different pneumatic line sizes in compact installations. Features triple-layer nickel plating (5-8μm thickness) for corrosion resistance and smooth O-ring seating. Internal flow path optimized for minimal pressure drop (ΔP <0.02MPa @1MPa).
- Branch line pressure regulation in automation equipment
- Tool changer interfaces on CNC machines
- Sensor air supply line adaptation
- Compressed air distribution in packaging machinery
- Vacuum system component integration
Installation protocol:
Apply thread sealant only on male threads (PTFE tape recommended).
Use backup wrenches during tightening to prevent port deformation.
Maximum torque: 14.7N·m for G1/8 side, 24.5N·m for G1/4 side.
| Property | Property Value |
|---|---|
| sku | X-APG1206 |
