Airtac X-APG Adapter - Reducing Straight Fitting X-APG1208
AirTAC X-APG1208 Reducing Straight Fitting Technical Details
- Model: X-APG1208
- Type: Compression-type reducing union
- Body material: Nickel-plated brass (ISO 1179 compliant)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Primary port size: PT1/8 (G1/8)
- Reduced port size: PT1/16 (G1/16)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 80℃ (continuous use)
- Surface hardness: ≥HV200 (electroless nickel plating)
- Thread standard: ISO 228-1 (parallel threads)
- Weight: 18g ±0.5g
- Dimensions: 20mm(L) × 12mm(OD at main port) × 8mm(OD at reduced port)
- Certification: RoHS 2011/65/EU compliant
Precision-machined flow adapter designed for secure stepped pneumatic connections in confined spaces. Features dual-seal structure with 360° compression grip and anti-vibration grooves. The stepped design allows smooth transition between different tubing diameters while maintaining laminar airflow (tested for ≤2% pressure drop at 10 L/min flow rate).
- Branch line creation in modular pneumatic systems
- Sensor mounting with smaller gauge tubing
- Robotic gripper tooling air supply adaptation
- Medical device pneumatic circuit miniaturization
- CNC machine tool cooling air distribution
Installation protocol:
Use two wrenches during assembly - one to counter-hold the main body (17mm hex flat)
and another to tighten the reduced port (10mm hex). Apply 3-4 N·m torque maximum.
Always install ferrule-type fittings before soldering operations.
