Airtac X-APG Adapter - Reducing Straight Fitting X-APG64
AirTAC X-APG64 Reducing Straight Fitting Technical Details
- Model Series: X-APG (Reducing Straight Connector Series)
- Thread Specifications: M5×0.8 (Male) to M3×0.5 (Female)
- Material: Lead-free brass with nickel plating (corrosion resistant)
- Seal Material: NBR (Nitrile) O-ring
- Pressure Rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature Range: -5℃ to 80℃ (23℉ to 176℉)
- Proof Pressure: 1.5 MPa
- Burst Pressure: 3.0 MPa
- Weight: 1.8±0.2 grams
- Dimensions: 12mm (L) × 8mm (W) × 8mm (H)
- Surface Roughness: Ra ≤3.2μm (sealing areas)
- Port Orientation: Axial straight-through design
- Compliance: RoHS 2.0 compliant
Precision-machined reducing connector enabling secure transition between different pneumatic line sizes. Features anti-vibration thread design with 360° rotatable male end for flexible installation. The electroless nickel coating provides enhanced chemical resistance compared to standard brass fittings.
- Branch line reductions in compact pneumatic manifolds
- Sensor air supply line connections
- Medical device pneumatic interfaces
- Robotic end-effector tubing adapters
- Precision valve pilot line configurations
| Property | Property Value |
|---|---|
| sku | X-APG64 |
