Airtac X-APH Hex Head Elbow Adapter X-APH1003
$4.87
Regular price
$12.37
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH1003
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH1003 Hex Head Elbow Swivel Connector Specifications
- Model: X-APH1003
- Type: Reusable 90° swivel elbow with hex nut
- Material: Nickel-plated brass body + PPS resin sleeve
- Thread Specification: PT1/8 (BSPP) female threads
- Tube Compatibility: Ø10mm OD polyurethane/nylon tubing
- Working Pressure: 0.05-1.5 MPa (7-217 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Swivel Angle: 360° continuous rotation capability
- Weight: 48g ±2g
- Dimensions: 35mm(L) × 16mm(W) × 16mm(H)
- Hex Size: 17mm wrench flat
- Seal Material: HNBR (Hydrogenated Nitrile) O-ring
- Vibration Resistance: ≤5Hz, amplitude ≤1.5mm
- IP Rating: IP40 (protected against 1mm particles)
High-torque elbow connector with anti-vibration locking design, featuring a dual-sealing structure (thread seal + tube grip) for leak-free performance in dynamic applications. The nickel-plated surface provides corrosion resistance against mild acids and industrial coolants.
Typical Applications:
- Pneumatic cylinder reorientation in robotic welding arms
- Compact space routing for CNC machine tool changers
- Modular conveyor system air supply connections
- Food processing equipment requiring frequent hose adjustments
- Medical device pneumatic circuits needing sterilizable fittings
Installation tip:
Hand-tighten until snug, then apply 1/4 turn with a torque wrench (max 2.5N·m).
For vacuum applications, apply silicone grease to O-ring before assembly.
Avoid overtightening – the swivel mechanism should rotate freely post-installation.
Compatibility Note:
Not recommended for use with phosphate ester hydraulic fluids or chlorinated solvents.
Maximum angular deflection under pressure: ±5° from neutral position.
Always perform pressure test at 1.25x working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APH1003 |
