Airtac X-APH Hex Head Elbow Adapter X-APH1004
AirTAC X-APH1004 Hex Elbow Swivel Joint Technical Details
- Model: X-APH1004
- Type: 360° rotatable hex elbow fitting
- Material: Brass (Nickel-plated surface)
- Thread specification: M5×0.8 female thread (both ends)
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile rubber)
- Surface roughness: Ra≤1.6μm
- Hex size: 8mm across flats
- Torque resistance: ≤2.5 N·m tightening torque
- Weight: 48±2 grams
- Dimensions: 34mm(L) × 18mm(W) × 28mm(H)
- Rotational friction: ≤0.3 N·m at 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP40 (protected against tool ingress)
Precision-machined swivel joint featuring full rotation capability with zero leakage up to 1.5MPa. The nickel-plated brass construction provides corrosion resistance in humid environments, while the 8mm hex design allows tool-free manual adjustment. Optimized flow path reduces pressure drop by 15% compared to standard elbows.
- Pneumatic tool quick-connect systems
- Robotic arm end-effector air supply
- Medical device gas line connections
- Packaging machine rotary unions
- Semiconductor fab equipment
- Food processing pneumatic controls
Installation protocol:
Apply 2-3 drops of pneumatic sealant (PST-3 type recommended) on threads before assembly.
Tighten using 8mm wrench with 1/4 turn past finger-tight position. Maximum 120° rotation
speed: 15 RPM. Avoid overtightening - audible click indicates proper seating.
| Property | Property Value |
|---|---|
| sku | X-APH1004 |
