Airtac X-APH Hex Head Elbow Adapter X-APH10M10
AirTAC X-APH10M10 Hexagonal Elbow Joint Technical Details
- Model: X-APH10M10
- Type: Reusable swivel elbow with hexagonal base
- Thread specification: M10×1.5 male thread (ISO 228 G1/8 equivalent)
- Material: Lead-free brass (CuZn39Pb0.5) with nickel plating
- Seal type: Integrated NBR O-ring (70±5 Shore A)
- Pressure rating: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -20℃ to 80℃ (continuous use)
- Torque resistance: ≤25 N·m tightening torque
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 28±2 grams
- Dimensions: 32mm(Length) × 22mm(Width) × 38mm(Height)
- Rotation angle: 360° free swivel with 30° deflection limit
- Fluid compatibility: Air, inert gases, non-flammable hydraulic fluids
High-precision swivel joint featuring a reinforced hexagonal base for tool-assisted installation. The cold-forged brass construction ensures leak-free performance under cyclic pressure loads. Optimized flow path design reduces turbulence with a 4.5mm internal bore diameter. Includes anti-vibration grooves for enhanced thread retention.
- Pneumatic tool hose connections in automotive assembly lines
- Modular piping systems for semiconductor manufacturing equipment
- Robotic arm end-effector pneumatic circuits
- Compressed air distribution in CNC machining centers
- Vacuum system manifolds for packaging machinery
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Use 17mm wrench on hex base while holding joint body stationary.
Maximum re-tightening cycles: 15 times. Replace if rotation becomes uneven.
| Property | Property Value |
|---|---|
| sku | X-APH10M10 |
