Airtac X-APH Hex Head Elbow Adapter X-APH10M20
AirTAC X-APH10M20 Hexagonal Elbow Joint Technical Details
- Model: X-APH10M20
- Type: Reusable swivel elbow with hexagonal base
- Thread specification: M20×1.5 external thread (ISO standard)
- Material: Anodized aluminum alloy body + POM (polyoxymethylene) rotating mechanism
- Tube compatibility: Ø10mm pneumatic tubing (soft nylon/PU)
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Rotation angle: 360° continuous rotation + ±15° axial tilt
- Seal type: Integrated NBR O-ring (replaceable)
- Surface treatment: Black electrophoretic coating
- Hex size: 27mm AF (across flats)
- Weight: 98g ±3g
- Dimensions: 62mm(L) × 38mm(W) × 27mm(H)
- Torque rating: Max 12 N·m installation torque
Multi-axis adjustable fitting designed for complex pneumatic line routing in confined spaces. Features double-locking mechanism with audible click engagement confirmation. The 8.5mm internal flow path minimizes pressure drop (ΔP ≤0.02MPa @ 0.5MPa input). Compatible with ISO 8434-1 standard fittings.
- Robotic arm end-effector pneumatic connections
- CNC machine tool automatic tool changer systems
- Assembly line positioning cylinder manifolds
- Semiconductor wafer handling equipment
- Packaging machine rotary union replacements
Maintenance protocol:
Apply silicone-free lubricant (Molykote EM-30L recommended) to O-ring groove
during reassembly. Tighten using 24mm crowfoot wrench for proper alignment.
| Property | Property Value |
|---|---|
| sku | X-APH10M20 |
