Airtac X-APH Hex Head Elbow Adapter X-APH1202
AirTAC X-APH1202 Hex Elbow Joint Technical Details
- Model: X-APH1202
- Type: Swivel-type external hex elbow joint
- Thread specification: M12×1.5 (male thread)
- Material: Nickel-plated carbon steel body + POM seal
- Hex size: 19mm wrench flat (per ISO 15444)
- Max torque resistance: 28 N·m
- Pressure rating: 0.02-1.0 MPa
- Temperature range: -20℃ to 80℃ (continuous use)
- Flow coefficient (Cv): 1.8
- Weight: 98g ±2g
- Dimensions: 52mm(L) × 33mm(W) × 28mm(H)
- Rotational angle: 360° continuous rotation
- Vibration resistance: ≤50 m/s²
Multi-axis adjustable elbow joint featuring anti-vibration locking grooves and dual O-ring seals. The chrome-moly steel construction withstands high torsional stresses in compact pneumatic circuits. Includes integrated dust shield for extended service life in particulate-heavy environments.
- Robotic arm end-effector pneumatic connections
- CNC machine tool coolant line adapters
- Food processing equipment (NSF-compliant version available)
- Plastic injection molding machine air lines
- Rail vehicle brake system manifolds
Mounting guidance:
Apply 2-3 drops of pneumatic sealant (Parker #6 or equivalent) on threads
before final tightening. Re-torque after 50 operating cycles. Avoid overtightening
beyond 32 N·m to prevent POM seat deformation.
| Property | Property Value |
|---|---|
| sku | X-APH1202 |
