Airtac X-APH Hex Head Elbow Adapter X-APH1203
AirTAC X-APH1203 Hexagonal Elbow Swivel Joint Technical Details
- Model: X-APH1203
- Type: Rotatable hexagon elbow joint with female thread
- Body material: Brass with nickel plating (CuZn39Pb3)
- Seal material: NBR (Nitrile) rubber
- Thread specifications:
- External thread: G1/8 (BSPP)
- Internal thread: M5×0.8
- Max working pressure: 0.7 MPa
- Min working pressure: 0.05 MPa
- Temperature range: -5℃ to 80℃
- Surface treatment: Electroless nickel plating (5-8μm)
- Hexagon size: 12mm across flats
- Weight: 42g ±2g
- Dimensions:
- Total length: 30mm
- Body width: 12mm
- Elbow angle: 90° fixed
- Port-to-port center distance: 18mm
- Vibration resistance: ≤10Hz @ 2mm amplitude
- ISO standard: 14771 (Pneumatic fluid power - Cylinder ports)
Precision-engineered swivel joint featuring 360° rotatable hex body for flexible tubing alignment in confined spaces. The nickel-plated brass construction ensures corrosion resistance in humid environments, while the NBR seals maintain integrity across temperature fluctuations. Designed for 50,000+ rotation cycles with <1° angular deviation under rated pressure.
- Pneumatic tool hose connections requiring angular adjustment
- Multi-axis robotic arm end effectors
- Compact medical gas delivery systems
- Packaging machine rotary unions
- Semiconductor equipment cooling lines
- Automated assembly fixture air circuits
Installation protocol:
Apply 2-3 drops of pneumatic sealant (Loctite 577 recommended) on male threads before assembly.
Tighten with 8-10 N·m torque using 12mm crowfoot wrench. Perform pressure test at 1.1× operating
pressure for 5 minutes post-installation. Re-torque after first 48hrs of operation.
- Oxygen-enriched atmospheres (>23%)
- Chlorinated hydrocarbons
- High-pressure water (>0.1 MPa)
| Property | Property Value |
|---|---|
| sku | X-APH1203 |
